Pass Through Single-Stage Parts Washing Systems
Our single stage conveyor parts washers are recommended for customers whose primary interest is the washing or rinsing of a production part in a continuous process. Conveyor, or pass through parts washers, are modular to provide flexibility and clean parts quickly.
Our single stage system is used if the dryness level of the part is not important, or if you can allow the part to flash dry. This system is available in mild steel or stainless steel. (Rinse systems available only in stainless steel).
Below are the specifications of our single stage conveyor style industrial parts washers.
| Model |
Construction |
Wash Pump |
Wash Heat |
Sump Capacity |
Overall Height |
Overall Length |
Overall Width |
Weight |
Amp Draw 230V |
Amp Draw 460V |
Amp Draw 575V |
Casters |
| I-1610W-GP |
Mild steel |
5 hp. |
27kW |
115 gal. |
56" |
62" |
57" |
1200 lbs |
77 |
9 |
31 |
x |
| I-1610W-GPSS |
Stainless steel |
5 hp. |
27kW |
115 gal. |
56" |
62" |
57" |
1200 lbs |
77 |
39 |
31 |
x |
| I-2412W-GP |
Mild steel |
5 hp. |
27kW |
135 gal. |
58" |
62" |
65" |
1500 lbs |
77 |
39 |
31 |
x |
| I-2412W-GPSS |
Stainless steel |
5 hp. |
27kW |
135 gal. |
58" |
62" |
57" |
1500 lbs |
77 |
39 |
31 |
x |
| I-2420W-GP |
Mild steel |
5 hp. |
48kW |
380 gal. |
5'9" |
12' |
7'1" |
2000 lbs |
130 |
65 |
52 |
|
| I-2420W-GPSS |
Stainless steel |
5 hp. |
48kW |
380 gal. |
5'9" |
12' |
7'1" |
2000 lbs |
130 |
65 |
52 |
|
These inline single-stage parts washers have other
accessories and options
available.
Please give us a call or use the quote request button on the right to provide more information on your production process.
We manufacture, ship and install industrial parts washers throughout North America, and are dedicated to providing seamless
integration into your production process. Call us at 877-465-4635 to speak with a product specialist.
